ECE Dept. Teaching Linux Client Status

For logins you upload your ssh key to Authman: https://uwaterloo.atlassian.net/wiki/spaces/ISTKB/pages/1551728653/How+to+use+SSH+Authman+-+for+users

Load
Num. Users

As of S2024 Ubuntu 24.04 is becoming the primary Linux.

As of W2019 Ubuntu is now the primary Linux. Login from off-campus with eceTerm.uwaterloo.ca or the use the campus VPN and then log into an eceUbuntu server. Note that the eceTerm.uwaterloo.ca servers are only to be used to then login (ssh -X) to a campus server will the work will be done.

Here is historical server load - Solaris Unix (2005 to 2011) and (CentOS 2011 to 2018)

The Server Groups

• Ubuntu2404 : eceUbuntu.uwaterloo.ca
• Ubuntu with a GPU : eceTesla.uwaterloo.ca
• Terminal Servers : eceTerm.uwaterloo.ca
• RedHat 8 Cadence Servers with OLD CPUs
• RedHat 8 Cadence Servers
• Ansys Misc RedHat 8 Servers
ECE Ubuntu Servers
Managed by Eric Praetzel

Machine	Machine Type	Location	Load Avg	Up-time	Extra Stats
eceubuntu2	No GPU Intel i5-8400 (Q3-2017) 6-core 2.8 to 4.0GHz Passmark 2374 / 9222 Asus B360M-Plus	DC Server Room	0.07 5 min 0.03 15 min 0.00	10 days 10:24	"Physical memory" 38% of 63G      "Shared memory" 100% of 23M "Swap space" 0% of 8G      "Available memory" 0% of 60G "/" 11% of 233G      "/opt" 70% of 228G Kernel 6.11.0-26 ( Ubuntu24.04.2 LTS) 248 Processes and 0 Users and ThinLinc 0, and IOPs 0.7, and CPUwait 0.00 %, and IPCM 4, and ALL IPC 10, and File Desc 5984, and CPU 30.0 C,
Total	1 of 1 machines up			load

ECE GPU Ubuntu Servers
Managed by Eric Praetzel

Machine	Machine Type	Location	Load Avg	Up-time	Extra Stats
eceubuntu1	Nvidia Tesla K40C 12GB 2880 CUDA cores 2013 Intel i5-8400 (Q3-2017) 6-core 2.8 to 4.0GHz Passmark 2374 / 9222	DC Server Room	0.37 5 min 0.25 15 min 0.15	10 days 10:24	"Physical memory" 73% of 63G      "Shared memory" 100% of 91M "Swap space" 0% of 8G      "Available memory" 0% of 55G "/" 42% of 456G      Kernel 6.11.0-26 ( Ubuntu24.04.2 LTS) 455 Processes and 0 Users and ThinLinc 0, and IOPs 2.0, and CPUwait 0.15 %, and IPCM 28, and ALL IPC 34, and File Desc 13792, and CPU 29.0 C, and GPU: 21.78 W , 29 C
ecetesla0	Nvidia Tesla P4 8GB 2560 CUDA cores 2016 Xeon Gold 5120 (Q3-2017) 14-core 2.2 to 3.2GHz SuperMicro X11SPG-TF Passmark 1725 / 18145	10Gb/s NIC   DC Server Room	0.01 5 min 0.10 15 min 0.17	10 days 17:04	"Physical memory" 31% of 93G      "Shared memory" 100% of 107M "Swap space" 0% of 8G      "Available memory" 0% of 86G "/" 43% of 456G      Kernel 6.11.0-26 ( Ubuntu24.04.2 LTS) 496 Processes and 0 Users and ThinLinc 0, and IOPs 1.0, and CPUwait 0.01 %, and IPCM 6, and ALL IPC 12, and File Desc 8848, and MB 31.0 C, and CPU 21.0 C, and GPU: 7.11 W , 27 C
ecetesla1	RTX 3070 8GB 5888 CUDA cores Ryzen9-5900X (Q3-2020) 12-core 3.7 to 4.8GHz Asus Pro WS x570-ACE Passmark 3502 / 39498	10Gb/s Intel NIC   DC Server Room	1.32 5 min 1.31 15 min 1.18	3 days 11:49	"Physical memory" 13% of 126G      "Shared memory" 100% of 67M "Swap space" 0% of 2G      "/" 39% of 915G "/database" 0% of 2.6T      Kernel 5.15.0-139 ( Ubuntu22.04 LTS) 882 Processes and 0 Users and ThinLinc 0, and TMUX 0, and IOPs 11.2, and CPUwait 0.03 %, and IPCM 9, and ALL IPC 15, and File Desc 3632, and GPU: 43.14 W , 41 C
ecetesla2	RTX 3070 8GB 2020 5888 CUDA cores Ryzen9-5900X (Q3-2020) 12-core 3.7 to 4.8GHz Asus Pro WS x570-ACE Passmark 3502 / 39498	10Gb/s Intel NIC   DC Server Room	1.64 5 min 1.46 15 min 1.67	10 days 10:24	"Physical memory" 47% of 126G      "Shared memory" 100% of 419M "Swap space" 0% of 8G      "Available memory" 0% of 114G "/" 22% of 915G      Kernel 6.11.0-26 ( Ubuntu24.04.2 LTS) 609 Processes and 1 Users and ThinLinc 0, and IOPs 3.8, and CPUwait 0.02 %, and IPCM 4, and ALL IPC 10, and File Desc 14912, and MB 32.2 C, and GPU: 25.23 W , 31 C
ecetesla3	GTX 1070 8GB 1920 CUDA cores Intel i7-7700K (Q1-2017) 4-core 4.2 to 4.5GHz Asus H170M-Plus Passmark 2750 / 9700	10Gb/s NIC   Thanks WEEF   DC Server Room	0.17 5 min 0.09 15 min 0.01	10 days 10:25	"Physical memory" 28% of 63G      "Shared memory" 100% of 200M "Swap space" 0% of 8G      "Available memory" 0% of 58G "/" 43% of 456G      Kernel 6.11.0-26 ( Ubuntu24.04.2 LTS) 306 Processes and 0 Users and ThinLinc 0, and IOPs 1.0, and CPUwait 0.01 %, and IPCM 4, and ALL IPC 10, and File Desc 8352, and CPU 31.0 C, and GPU: 5.89 W , 27 C
ecetesla4	RTX 3070 8GB 5888 CUDA cores Ryzen9-5900X (Q3-2020) 12-core 3.7 to 4.8GHz Asus Prime B350M-A Passmark 3502 / 39498	10Gb/s Intel NIC   DC Server Room	0.00 5 min 0.00 15 min 0.00	3 days 10:12	"Physical memory" 12% of 126G      "Shared memory" 100% of 76M "Swap space" 0% of 8G      "Available memory" 0% of 120G "/" 21% of 915G      Kernel 6.11.0-28 ( Ubuntu24.04.2) 434 Processes and 0 Users and ThinLinc 0, and IOPs 1.3, and CPUwait 0.01 %, and IPCM 4, and ALL IPC 10, and File Desc 6736, and MB 24.0 C, and GPU: 7.07 W , 32 C
eceubuntu4	GTX 1070 8GB 1920 CUDA cores Intel i5-8400 (Q3-2017) 4-core 3.4 to 4.0GHz Passmark 2374 / 9222 Asus B360M-Plus	DC Server Room	0.07 5 min 0.04 15 min 0.01	10 days 10:24	"Physical memory" 17% of 63G      "Shared memory" 100% of 4.3M "Swap space" 0% of 8G      "Available memory" 0% of 61G "/" 43% of 456G      Kernel 6.11.0-26 ( Ubuntu24.04.2 LTS) 247 Processes and 0 Users and ThinLinc 0, and IOPs 1.2, and CPUwait 0.00 %, and IPCM 4, and ALL IPC 10, and File Desc 5344, and CPU 33.0 C, and GPU: 5.59 W , 30 C
Total	7 of 7 machines up with 1 Users			load

Cadence Course Linux Servers
MENTOR CALIBRE DOES NOT WORK
Managed by the Eric Praetzel

Machine	Machine Type	Location	Load Avg	Up-time	Extra Stats
iccad1	2 Xeon E5-2667 v2 (Q3-2013) each 8-core 3.3 to 4.0GHz Dell R620 NO AVX2 NOT FOR CALIBRE Passmark 2035 / 21339	DC Server Room	1.00 5 min 0.84 15 min 0.61	10 days 12:49	"Physical memory" 6% of 503G      "Shared memory" 100% of 442M "Swap space" 0% of 7.8G      "Available memory" 0% of 484G "/" 25% of 70G      "/opt" 33% of 386G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 1058 Processes and 7 Users and ThinLinc 5, and IPCM , and ALL IPC , and CPU 25.0 C,
iccad2	2 of Xeon E5-2667 v2 (Q3-2013) each CPU 8-core 3.3 to 4.0GHz Dell R620 NO AVX2 NOT FOR CALIBRE Passmark 2035 / 21339	DC Server Room	0.00 5 min 0.02 15 min 0.00	10 days 16:58	"Physical memory" 13% of 188G      "Shared memory" 100% of 170M "Swap space" 0% of 4G      "Available memory" 0% of 182G "/" 31% of 70G      "/opt" 80% of 157G "/CMC" 48% of 12T      Kernel 4.18.0-553.56.1 (el8_10.x86_64 RedHat EL 8) 571 Processes and 1 Users and ThinLinc 1, and IPCM , and ALL IPC , and CPU 29.0 C,
iccad3	2 of Xeon E5-2667 v2 (Q3-2013) each CPU 8-core 3.3 to 4.0GHz Dell R620 NO AVX2 NOT FOR CALIBRE Passmark 2035 / 21339	DC Server Room	0.00 5 min 0.00 15 min 0.00	10 days 12:45	"Physical memory" 4% of 503G      "Shared memory" 100% of 3.2G "Swap space" 0% of 7.8G      "Available memory" 0% of 485G "/" 18% of 70G      "/opt" 33% of 386G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 803 Processes and 4 Users and ThinLinc 4, and IPCM , and ALL IPC , and CPU 32.0 C,
Total	3 of 3 machines up with 12 Users			load

Cadence Course Linux Servers
AuthMan ssh keys recommended
WITH AVX2 for MENTOR CALIBRE
Managed by the Eric Praetzel

Machine	Machine Type	Location	Load Avg	Up-time	Extra Stats
iccad0	2 Xeon Gold 6136 (Q3-2017) each 12-core 3.0 to 3.7GHz Dell R640 Passmark 2169 / 35604	Thanks WEEF  DC Server Room	1.38 5 min 1.98 15 min 2.07	10 days 13:47	"Physical memory" 6% of 251G      "Shared memory" 100% of 117M "Swap space" 0% of 4G      "Available memory" 0% of 243G "/" 23% of 70G      "/opt" 55% of 228G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 1154 Processes and 2 Users and ThinLinc 2, and IPCM , and ALL IPC , and CPU 30.0 C,
iccad4	2 Xeon E5-2670 v3 (Q3-2014) each 12-core 2.3 to 3.1GHz Dell R530 Passmark 1700 / 13800	DC Server Room	0.02 5 min 0.03 15 min 0.00	3 days 10:16	"Physical memory" 5% of 251G      "Shared memory" 100% of 113M "Swap space" 0% of 4G      "Available memory" 0% of 244G "/" 20% of 70G      "/opt" 55% of 228G "/CMC" 48% of 12T      "/opt/sentinelone/rpm_mount" 20% of 70G Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 527 Processes and 1 Users and ThinLinc 1, and IPCM , and ALL IPC , and CPU 58.0 C,
iccad6	2 of Xeon E5-2637 v4 (Q3-2016) each CPU 4-core 3.5 to 3.7GHz Thinkstation P910 Passmark 2198 / 7370	DC Server Room	0.06 5 min 0.07 15 min 0.03	10 days 13:43	"Physical memory" 5% of 157G      "Shared memory" 100% of 43M "Swap space" 0% of 4G      "Available memory" 0% of 153G "/" 18% of 70G      "/opt" 14% of 948G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 399 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC , and MB 76.0 C, and CPU 40.0 C,
iccad7	2 Xeon Gold 6136 (Q3-2017) each 12-core 3.0 to 3.7GHz Dell R640 Passmark 2169 / 35604	DC Server Room	0.00 5 min 0.00 15 min 0.00	10 days 13:43	"Physical memory" 2% of 251G      "Shared memory" 100% of 41M "Swap space" 0% of 4G      "Available memory" 0% of 247G "/" 19% of 70G      "/opt" 54% of 228G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 823 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC , and CPU 24.0 C,
iccad8	2 Xeon Gold 6136 (Q3-2017) each 12-core 3.0 to 3.7GHz Dell R640 Passmark 2169 / 35604	DC Server Room	0.00 5 min 0.00 15 min 0.00	10 days 13:40	"Physical memory" 2% of 251G      "Shared memory" 100% of 41M "Swap space" 0% of 4G      "Available memory" 0% of 247G "/" 19% of 70G      "/opt" 54% of 228G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 822 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC , and CPU 26.0 C,
iccad9	2 Xeon Gold 6136 (Q3-2017) each 12-core 3.0 to 3.7GHz Dell R640 Passmark 2169 / 35604	Thanks WEEF   DC Server Room	0.00 5 min 0.00 15 min 0.00	10 days 13:41	"Physical memory" 61% of 376G      "Shared memory" 100% of 193M "Swap space" 0% of 4G      "Available memory" 0% of 371G "/" 34% of 70G      "/opt" 54% of 228G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 647 Processes and 1 Users and ThinLinc 0, and IPCM , and ALL IPC , and CPU 22.0 C,
iccad10	2 Xeon Gold 6154 (Q3-2017) each 18-core 3.0 to 3.7GHz Ansys 2024R1 RSM Dell R640 Passmark 2239 / 28632	Thanks WEEF   DC Server Room	0.08 5 min 0.04 15 min 0.01	10 days 17:03	"Physical memory" 8% of 376G      "Shared memory" 100% of 127M "Swap space" 0% of 4G      "Available memory" 0% of 368G "/" 40% of 70G      "/opt" 54% of 228G "/CMC" 48% of 12T      Kernel 4.18.0-553.56.1 (el8_10.x86_64 RedHat EL 8) 925 Processes and 2 Users and ThinLinc 1, and IPCM , and ALL IPC , and CPU 34.0 C,
iccad11	2 Xeon Gold 6154 (Q3-2017) each 18-core 3.0 to 3.7GHz Dell R640 Passmark 2239 / 28632	Thanks WEEF   DC Server Room	0.00 5 min 0.00 15 min 0.00	10 days 13:42	"Physical memory" 48% of 376G      "Shared memory" 100% of 66M "Swap space" 0% of 4G      "Available memory" 0% of 371G "/" 19% of 70G      "/opt" 54% of 228G "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 647 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC , and CPU 27.0 C,
iccad12	2 Xeon Gold 6154 (Q3-2017) each 18-core 3.0 to 3.7GHz Dell R640 Passmark 2239 / 28632	DC Server Room	0.04 5 min 0.06 15 min 0.07	10 days 13:33	"Physical memory" 3% of 376G      "Shared memory" 100% of 49M "Swap space" 0% of 4G      "Available memory" 0% of 369G "/" 23% of 70G      "/opt" 26% of 1.1T "/CMC" 48% of 12T      Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 838 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC , and CPU 31.0 C,
iccad13	2 Xeon Gold 6154 (Q3-2017) each 18-core 3.0 to 3.7GHz Dell R640 Passmark 2239 / 28632	DC Server Room	0.08 5 min 0.12 15 min 0.15	10 days 17:03	"Physical memory" 4% of 376G      "Shared memory" 100% of 145M "Swap space" 0% of 4G      "Available memory" 0% of 371G "/" 22% of 70G      "/opt" 26% of 1.1T "/CMC" 48% of 12T      Kernel 4.18.0-553.52.1 (el8_10.x86_64 RedHat EL 8) 824 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC , and CPU 29.0 C,
Total	10 of 10 machines up with 6 Users			load

RHEL 8 Linux Ansys Servers
Login with AuthMan ssh keys ONLY
Managed by the Eric Praetzel

Machine	Machine Type	Location	Load Avg	Up-time	Extra Stats
iccad5	2 of Xeon E5-2620 v4 (2016) each 8-core 2.1 to 3.0GHz Huawei Passmark 1630 / 9224	DC Server Room	0.22 5 min 0.07 15 min 0.02	3 days 13:18	"Physical memory" 2% of 503G      "Shared memory" 100% of 76M "Swap space" 0% of 4G      "Available memory" 0% of 494G "/" 92% of 70G      "/opt/sentinelone/rpm_mount" 92% of 70G Kernel 4.18.0-553.42.1 (el8_10.x86_64 RedHat EL 8) 622 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC , and CPU 26.0 C,
eceansys.eng	2 of Xeon E5-2620 (2012) each 6-core 2.0 to 2.5GHz Ansys 2024R1 RSM Dell R720 Passmark 1110 / 9802	DC Server Room	0.01 5 min 0.02 15 min 0.00	10 days 13:23	"Physical memory" 27% of 62G      "Shared memory" 100% of 1.3G "Swap space" 0% of 23G      "Available memory" 0% of 58G "/" 75% of 70G      "/opt/sentinelone/rpm_mount" 75% of 70G Kernel 4.18.0-553.58.1 (el8_10.x86_64 RedHat EL 8) 316 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC ,

ECE Terminal Servers
Managed by the Eric Praetzel

Machine	Machine Type	Location	Load Avg	Up-time	Extra Stats
eceTerm0	i5-8400 (Q3-2017) for ThinLinc and SSH only	DC Server Room TESTING	0.07 5 min 0.08 15 min 0.04	10 days 10:14	"Physical memory" 50% of 7.5G      "Shared memory" 100% of 162M "Swap space" 0% of 2.5G      "Available memory" 0% of 6.1G "/" 42% of 21G      Kernel 5.14.0-570.23.1 (el9_6.x86_64 RedHat EL 9) 231 Processes and 0 Users and ThinLinc 0, and IPCM , and ALL IPC ,
eceTerm1	VM 2-core for ThinLinc and SSH only	DC Server Room	0.26 5 min 0.26 15 min 0.24	10 days 10:13	"Physical memory" 91% of 16G      "Shared memory" 100% of 98M "Swap space" 0% of 4G      "Available memory" 0% of 13G "/" 60% of 24G      Kernel 6.8.0-60 ( Ubuntu22.04.5) 364 Processes and 3 Users and ThinLinc 2, and TMUX 1, and IOPs , and CPUwait %, and IPCM 25, and ALL IPC 31, and File Desc 14496,
eceTerm2	VM 2-core for ThinLinc and SSH only	DC Server Room	1.09 5 min 1.03 15 min 1.00	10 days 10:14	"Physical memory" 33% of 16G      "Shared memory" 100% of 2.8M "Swap space" 0% of 4G      "Available memory" 0% of 14G "/" 59% of 24G      Kernel 6.8.0-60 ( Ubuntu22.04.5) 167 Processes and 0 Users and ThinLinc 0, and TMUX 0, and IOPs , and CPUwait %, and IPCM 4, and ALL IPC 10, and File Desc 5600,
eceTerm3	i5-9400 (Q1-2019) for ThinLinc and SSH only	DC Server Room	0.05 5 min 0.31 15 min 0.23	10 days 10:13	"Physical memory" 40% of 31G      "Shared memory" 100% of 142M "Swap space" NA% of 0      "Available memory" 0% of 29G "/" 5% of 228G      Kernel 6.8.0-60 ( Ubuntu22.04.5) 288 Processes and 2 Users and ThinLinc 0, and TMUX 0, and IOPs 4.7, and CPUwait 0.02 %, and IPCM 4, and ALL IPC 10, and File Desc 8640, and MB 25.0 C, and CPU 38.0 C,
Total	4 of 4 machines up with 5 Users			load

Run finished at: Sat 05 Jul 2025 08:10:53 PM EDT

Load graphs for all machines

Historical Load : Sun Solaris Machines (2005 to 2011) : CentOS 2011 to 2018



Operating System	Current Kernel
CentOS5 EOL	2.6.18-419
CentOS6 EOL	2.6.32-754.27.1
CentOS7 EOL	3.10.0-1160.119.1
Ubuntu18.04 LTS EOL	4.15.0-136
Ubuntu18.10 EOL	4.17.0-36
RedHat EL 8.10	4.18.0-553.50.1
Ubuntu19.04 EOL	5.0.0-41
Ubuntu20.04.2 LTS	5.13.0-52
RedHat EL 9	5.14.0-570.19.1
Ubuntu20.04.6 LTS	5.15.0-134
Ubuntu22.04 OEM	5.17.0-1019
Ubuntu22.04 LTS2	5.19.0-45
Ubuntu18.04 HWE	5.4.0-132
Ubuntu22.04 OEM2	6.0.0-1019
Ubuntu24.04.2 LTS	6.11.0-26
Ubuntu22.04.3 LTS	6.5.0-45
Ubuntu22.04.5 LTS	6.8.0-52



Scientific Linux (RedHat 7) machines shut down September 2024 and Cadence is now run on RedHat 8. CPUs without AVX2 can not run Matlab R2024+ or Mentor Calibre 2024+

Sun Solaris OS & hardware was used until 2011 peaking at a 30 CPU Sun 6500 machine.

CentOS Linux started to be used in 2009 on Intel Pentium dual-core machines as they offered 10x the performance at 1/10 the power draw.

In F2018 the primary Linux OS became Ubuntu 18.04 LTS because of it's inclusion of current versions of software tools, support of newer CPUs and aprox. 3x the performance in heavily multi-threaded use.
